XMT-708 Series Universal Intelligent Temperature Controller

Ⅰ Main technical specification l Measurement deviation: ≤±0.5%F·S±1 l Cold end compensating deviation: ≤±2.0℃ l Sampling cycle: 0.5S l Control cycle: relay output 2～120S , other is 2S. l Relay output contact capacity: AC220V/7A (resistance load) l Power: AC85V～242V, 50/60Hz l Working condition: temperature 0～50.0℃, relative humidity≤85%RH, without corrode and strong electric radiation. Ⅱ Code setting mode Series Code Name Setting range Manual Remarks 0 SP Fixed value Determined by P-SL P-SH － 50.0 1 AL-1 Alarm 1 Determined by P-SL,P-SH when the upper and lower limit range,it is0～50.0 when the upper and lower limit deviation alarm Alarm 1 setting value 10 2 AL-2 Alarm 2 Determined by P-SL,P-SH when the upper and lower limit range,it is0～50.0 when the upper and lower limit deviation alarm Alarm 1 setting value 10 3 P Proportion modulus 0～100 When the P↑,the the proportion function↓ When P=0,the meter…
